| Specification |
|---|
| MOTHERBOARD |
| Form factor |
Mini ITX, mATX, μATX, ATX |
| max. Motherboard size |
305mm x 270mm (12" x 10.6") |
| INSTALLATION DIMENSIONS |
| Height CPU cooler (max.) |
130mm³ |
| Length graphics card (max.) |
275mm⁴ |
| DRIVE BAYS |
|
| 5.25" external |
3x / 2x¹ |
| 3.5" external |
/ 1x¹ |
| 3.5" internal |
8x |
| 2.5" internal |
7x² |
| FRONT CONNECTORS |
| USB 3.0 |
|
| USB 2.0 |
2x |
| POWER SUPPLY |
| PS2/mini redundant PSU |
|
| ATX PSU |
| FAN MOUNTING OPTION |
| Front |
1x 120mm (serial, Molex connector) |
| Rear |
2x 80mm (optional) |
| CONTROLS & LED |
| Controls |
Power-Button
Reset-Button |
| LED |
Power
HDD Activity |
| OTHER DATA |
| Dimensions (h/w/d) |
178 x 485 x 483mm |
| Material |
1.0-1.2mm Steel |
| Warranty |
1 months |
| SCOPE OF DELIVERY & FEATURES |
| Scope of delivery |
Case
Retail packaging
Keys
Screw Set
Mounting frame 5.25" to 3.5" external |
| Features |
Removable HDD cages
7x screwed and perforated brackets (backside)
Slot Card holder each 1x for short, mid and high Slot Cards
Lockable front door
USB 2.0 internal as block connector |
| LOGISTICAL DATA |
| Weight |
net = 10.00kgs
gross = 12.10kgs |
| Item number |
88887178 |
| EAN-Code |
4260133128101 |
